1 C CMS530.noname1 E7.2 /GICWINSHOP 21.09.2018 15:36:58 <M1> 6.8.035 Build 1 Release (gb) #139=566 #156=0 <SETUP2>
11 C NP1=9.0 Setup Row
12 C NP2=11.0 Tubular Cycle front
13 C NP3=11.0 Tubular Cycle rear
14 C NP4=9.5 Transition-RR
15 C NP5=12.0 Struc Single jersey front
16 C NP6=12.0 Struc Single jersey rear
17 C NP11=7.0 Setup Row front
18 C NP17=12.0 Safety rows
19 C NP20=9.0 Start 1
20 C NP21=10.0 Start 2
21 C NP22=11.0 Start 3
22 C NP23=11.5 Start 4
23 C NP24=12.0 Start 5
24 C NP25=18.0 Comb Thread
25 C MSECI=0.70
39 IF #L=0 #L=1 IF #R=0 #R=699 #LM=0 #RM=0
40 START
41 C #98=0 C Cast-off On/Off (#98=0)
42 C #69=0 C MS*#69 (1-4s) (#69=1..4)
43 PF0
44 Y-CR1
50 YGC:1F=A 2F=B/2F=C 8F=D;
51 YDF=2
52 C------------------------------------I------------------------------------I
53 C LEFT I RIGHT I
54 C------------------------------------I------------------------------------I
55 C I 8=D Protection thread 1 I
56 C 2=B Comb thread1 I 2=C Rib thread 1 I
57 C 1=A Draw thread1 I I
58 C------------------------------------I------------------------------------I
59 YD YC
80 FBEG:M1-SIZES;
81 F1=1-699
82 PA:JA1; PAI:JA1;
83 PM:1:F1; SEN=1-699 #51=1 #52=699
84 Y-2B:HR1G;
85 FEND C M1-SIZES
86 JA1=1320(1100-1100)
110 #99=0
111 IF RS17=0 S0Y #99=1 W0
112 IF RS17=1 S0YCR0 #99=1 W0
113 IF #99=1 #99=0 MS PRINT/CHECK YARN CARRIER/
114 F:M1-SINTRAL;
115 END
116 FBEG:M1-SINTRAL;
117 IF RS17=0 F:SWITCH-1; C Comb On/Off
118 IF RS17=0 F:SWITCH-4; C Comb On/Off
119 JA1=1310 #L=276 #LM=0 #RM=0 #R=425
120 << S:<1-><+>A(21)-Y(21); Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD1.0-1.0; S3 W+F50 W0 MSEC3
121 IF RS17=0 F:SWITCH-5; C Comb On/Off
122 JA1=1285 #L=276 #LM=0 #RM=0 #R=425
123 F:M1-SIZES;
124 >> S:<1-><+>A(22)-Y(22); Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD1.0-1.0; S1 WMF1 MSEC3
125 IF RS15<>0 F:CYCLE-8; C Protection thread
126 JA1=1282 #L=276 #LM=0 #RM=0 #R=425
127 << S:<1->UVS+/<1->UVS+/<1-><+>AH(23)-H(21); Y:=D; V0 YC S1 S2 Y-8A:F1+^0; Y-8A:YD1.0-1.0; S3 WMF1 MSEC3
128 >> S:<1-><+>AH(23)-H(21)/<1->%*-*/<1-><B>A(24)-0; Y:=D/0/=A; Y-8A:YD1.0-13.0; S1 S2 Y-1A:F1B^0; Y-1A:YD7.0-1.0; S3
129 << S:<1-><B>A(24)-0/<1-><A>H(1)-H(11); Y:=A/=C; S1 Y-2B:HL1 HR1 F1A^0; Y-2B:YD1.0-7.0; S2
130 >> S:<1-><A>A(2)-0; Y:=C; Y-2B:YD1.0-1.0; S2
131 << S:<1-><A>0-Y(3); Y:=C; S2
132 >> S:<1-><A>A(2)-0; Y:=C; S2
133 IF RS1<>0 F:CYCLE-9; C Tubular Cycle
134 JA1=1269 #L=276 #LM=0 #RM=0 #R=425
135 << S:<1-><A>0-Y(3); Y:=C; V0 Y-2B:HL1 HR1 F1A^0; YC Y-2B:YD1.0-1.0; S2 WMF1 MSEC3
136 >> S:<1-><A>H(4)-H(4); Y:=C; S2
137 SBEG
138 Y-2A:HL0 HR0 F1*^0;
139 IF RS17=0 Y-2A:C; V0 YC S1
140 << S:<1->UVS+/<1->UVS+; V0 S2 S3
141 SEND
142 >> VU S0 W0
143 << S:<1-><A>A(5)-0; Y:=C; VU S3 WMF1 W+F1 MSEC2
144 REP*74
145 >> S:<1-><A>A(5)-0; Y:=C; VU S1
146 << S:<1-><A>A(5)-0; Y:=C; VU S3
147 REPEND
148 >> S:<1-><A>A(5)-0; Y:=C; VU S1
149 REP*5
150 << S:<1-><A>A(17)-0; Y:=C; VU S3
151 >> S:<1-><A>A(17)-0; Y:=C; VU S1
152 REPEND
153 << S:<1-><A>A(17)-0; Y:=C; VU S3
154 RS17=1 IF #100=1 RS17=0
155 >> S:<1-><A>A(17)-0; Y:=C; VU Y-2B:HL0 HR1; S1
156 IF RS17=0 F:SWITCH-10; C Cast off
157 FEND C M1-SINTRAL
158 C ---------- Comb On/Off ----------
159 FBEG:SWITCH-1;
160 IF #98=0 F:SWITCH-2; C Cast-off On/Off
161 IF #140=1 F:SWITCH-3; GOTO #123 C Comb of lower Limit Switch
162 JA1=1318 #L=1 #LM=0 #RM=0 #R=699
163 IF#99=1 #99=0 MS PRINT/! ! CHECK COMB ! !/
164 << V0 =-= S0 WMF2 MSEC=0.70 LK1
165 IFN#137=72 MS PRINT/! ! INVALID GAUGE ! !/
166 >> S:<1-><*>A(25)-Y(25)/<1->H(20)-H(20); Y:=B/0; Y-2A:HL0 HR1 R25 F1*^0; Y-2A:YD-1.0; #R<273 S2 S3
167 << S:<1-><*>A(25)-Y(25)/<1->H(20)-H(20); Y:=B!/0; Y-2A:HL2 HR1; S1 S2
168 =^= #98=0 VU
169 >> S0 W0
170 FEND C Comb On/Off
171 C ---------- Cast-off On/Off ----------
172 FBEG:SWITCH-2;
173 JA1=1320 #L=1 #LM=0 #RM=0 #R=699
174 AS1
175 << S0 W0
176 >> S:<1->H(20)-H(20); Y:0; S1 WMF3 MSEC=1.00
177 << S:<1->H-H; Y:0; V0 S1 WMF2
178 AS0
179 >> S0
180 FEND C Cast-off On/Off
181 C ---------- Comb of lower Limit Switch ----------
182 FBEG:SWITCH-3;
183 JA1=1318 #L=1 #LM=0 #RM=0 #R=699
184 << V0 S0 WMF2 MSEC=1.00
185 #99=1
186 >> S0
187 FEND C Comb of lower Limit Switch
188 C ---------- Comb On/Off ----------
189 FBEG:SWITCH-4;
190 JA1=1314 #L=276 #LM=0 #RM=0 #R=425
191 << S:<1->UXST-+/<1-><+>N.-0; Y:=D; V0 S2 Y-8A:F1+^0; S3 W0 MSEC3
192 >> VU #R>274 S0 W0
193 << S:<1->UXST%A-+%Y; S3 W0 MSEC3
194 >> S:<1-><+>A(21)-Y(21); Y:=D; VU Y-8A:YD-1.0; #R<274 S1 W0
195 FEND C Comb On/Off
196 C ---------- Comb On/Off ----------
197 FBEG:SWITCH-5;
198 JA1=1309 #L=276 #LM=0 #RM=0 #R=425
199 >> S:<1->UXST-+/<1-><+>A(21)-Y(21)/<1->UVS+; Y:=D; V0 YC S1 Y-8A:F1+^0; Y-8A:YD1.0-1.0; S2 S3 W0 MSEC3
200 << S:<1-><+>A-0/<1-><A>N.-0; Y:=D/=C; VU S1 Y-2B:HL0 HR1 F1A^0; S2 W0
201 >> VU #R>274 S0 W0
202 << S:<1->UXST%A-+%Y/<1->A-Y; Y:0; S1 S2 W0
203 >> S:<1-><A>A-0/<1-><+>A-Y/<1->UXST-+; Y:=C/=D; Y-2B:YD-7.0; #R<274 S1 S2 S3 W0
204 << S:<1-><+>A-Y/<1->UVS+; Y:=D; S2 S3 W0
205 Y-RALL
206 >> S:<1-><+>A-0/<1-><B>N.-0; Y:=D/=A; VU S1 Y-1A:F1B^0; S2 W0
207 << VU #L<275 S0 W0
208 >> S:<1->UXST%A-+%Y/<1->A-Y; Y:0; S1 S2 W0
209 << S:<1-><B>0-Y; Y:=A; VU Y-1A:YD7.0; #L>275 S2 W0
210 >> VU S0 W0
211 IF RS18=>1 IF RS18<=5 F:SWITCH-6; C Compensation Float and Lock
212 JA1=1286 #L=276 #LM=0 #RM=0 #R=425
213 Y-RALL
214 << S:<1-><+>A(21)-Y(21); Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD1.0-45.0; S3 W0 MSEC3
215 FEND C Comb On/Off
216 C ---------- Compensation Float and Lock ----------
217 FBEG:SWITCH-6;
218 JA1=1292 #L=276 #LM=0 #RM=0 #R=425
219 << S:<1-><+>N.-0; Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD45.0-1.0; S3 W0 MSEC3
220 >> S:<1-><+>A(21)-Y(21); Y:=D; VU Y-8A:YD45.0-45.0; S1 WMF1
221 IF RS18<>0 F:CYCLE-7; C Compensation Float and Lock
222 JA1=1288 #L=276 #LM=0 #RM=0 #R=425
223 << S:<1-><+>A(21)-Y(21); Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD45.0-45.0; S3 WMF1 MSEC3
224 >> S:<1-><+>N.-0; Y:=D; VU S1 W0
225 FEND C Compensation Float and Lock
226 C ---------- Compensation Float and Lock ----------
227 FBEG:CYCLE-7;
228 RBEG*RS18
229 JA1=1290 #L=276 #LM=0 #RM=0 #R=425
230 << S:<1-><+>A(21)-Y(21); Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD45.0-45.0; S3 WMF1 MSEC3
231 >> S:<1-><+>A(21)-Y(21); Y:=D; VU S1
232 REND
233 FEND C Compensation Float and Lock
234 C ---------- Protection thread ----------
235 FBEG:CYCLE-8;
236 RBEG*RS15
237 JA1=1284 #L=276 #LM=0 #RM=0 #R=425
238 << S:<1-><+>A(22)-Y(22); Y:=D; VU V0 Y-8A:F1+^0; YC Y-8A:YD1.0-1.0; S3 WMF1 MSEC3
239 >> S:<1-><+>A(22)-Y(22); Y:=D; VU S1
240 REND
241 FEND C Protection thread
242 C ---------- Tubular Cycle ----------
243 FBEG:CYCLE-9;
244 RBEG*RS1
245 JA1=1271 #L=276 #LM=0 #RM=0 #R=425
246 << S:<1-><A>0-Y(3); Y:=C; V0 Y-2B:HL1 HR1 F1A^0; YC Y-2B:YD1.0-1.0; S2 WMF1 MSEC3
247 >> S:<1-><A>A(2)-0; Y:=C; S2
248 REND
249 FEND C Tubular Cycle
250 C ---------- Cast off ----------
251 FBEG:SWITCH-10;
252 JA1=1103 #L=276 #LM=0 #RM=0 #R=425
253 << Y-1A:C; V0 S1 MSEC=0.70 W0
254 >> Y-8A:C; S1Y-2B:C; S2 W0
255 << S:<1->H(17)-H(17)/<1->H-H; Y:0/0; S1 S2 WMF4
256 #98=1
257 >> S:<1->H-H/<1->H-H; Y:0/0; S2 S3 WMF2 MS=2.5
258 IF #69=>1 IF #69<=4 F:SWITCH-11; C MS*#69 (1-4s)
259 FEND C Cast off
260 C ---------- MS*#69 (1-4s) ----------
261 FBEG:SWITCH-11;
262 JA1=1100 #L=276 #LM=0 #RM=0 #R=425
263 << V0 YC S0 WMF2 MSEC=0.70
264 IF#69=1 MS=1
265 IF#69=2 MS=2
266 IF#69=3 MS=3
267 IF#69=4 MS=4
268 >> S0
269 FEND C MS*#69 (1-4s)
999 S0 W0
